What is the EA-6B Prowler?

By: Yohan Lee

The EA-6B Prowler is an Electronic Warfare aircraft and was built by Northrop Grumman. The Prowler uses an A-6 Intruder airframe and was used in the Navy and Marines.

What is Electronic Attack?

Electronic Attack is used for tactical jamming and is also called Electronic Warfare or EW. The EA in EA-6B Prowler stands for Electronic Attack. The Prowler can disrupt enemy radar and radio communications. What makes the Prowler unique is that it can jam ground signals like mobile phones, garage openers and most importantly, improvised explosive devices or IED. Since it can jam IEDs and prevent them from detonating it makes the troops on the ground much safer with a higher success rate on their missions. The Prowler was so powerful that the Pentagon made sure that no U.S. aircraft carriers went into battle without the Prowler. “Since the Prowler technology was so advanced, the Pentagon had the technology and pilots classified,” said Capt. David Woods.

History

During the Vietnam War there were many anti aircraft weapons and the U.S. kept losing planes to them so Northrop Grumman made the A-6B Prowler to have 4 seats instead of 2. There would be 1 pilot and 3 electronic warfare officers, or EWO.

Naval Air Station Whidbey Island is known to be the home of Electronic Warfare. NAS Whidbey Island would receive the first EA-6B Prowler in 1971. The EA-6B Prowler was first put into squadron VAQ-129 for Fleet Replacement testing, then VAQ-132, or the Scorpions, for deployment. Then, later on, they would deploy the EA-6B Prowler to Vietnam in 1972.

But the first EA-6A was first brought to the Marines for Electronic Attack in December 1965. The EA-6A is an A-6 Intruder and unlike the EA-6B of having 4 seats, it has 2 seats. The avionics for Electronic Attacks were much smaller than the EA-6B Prowler. The Navy took 3 EA-6A from the Marines and made it into the EA-6B. Once the EA-6B Prowler was made, the Marines retired the EA-6A and serviced the EA-6B Prowler.

The Navy first retired the Prowler on May 27th, 2015 and transitioned the Prowler to the E/A-18G Growler which is an F-18F Super Hornet with more advanced jamming. The Marines retired their Prowler in March 2019 and also transitioned to the Growler.

Not only was the Prowler deployed in the Vietnam War but it also was deployed in Syria, Afghanistan, and Iraq. The Prowler was also deployed in the Invasion of Grenada and Operation El Dorado Canyon. During Operation Desert Storm, 39 Prowler were deployed in the Gulf War and fired up to 150 HARM-88 missiles, and came back with no losses.

Avionics

  • AN/ALQ-218 Tactical Jamming System Receiver
  • AN/USQ/-113 Communication Jamming System
  • At the top of the tail is an antenna that receives radar and radio signals.

Armament

The Prowler can have up to:

  • 4x AGM-88 HARM Anti Radiation Missiles
  • 5x 300 Gallon External Drop Tank
  • 5x AN/ALQ-99 Tactical Jamming System External Pods
  • AN/ALE-43 Chaff Dispense System Pod
  • AN/AAQ-28 Litening Pod

Aircraft Specification

  • Length: 59 feet
  • Height: 16 feet
  • Wing Span: 53 feet
    • Wing Folded: 25 feet
  • Maximum Take off Weight: 61,500 pounds
  • Thrust: 11,200 pounds per engine 22,400 total
  • Airspeed: Max .99 or 659 mph / cruise .72 Mach or 481 mph
  • Maximum Range: 850 nautical miles
  • Service Ceiling: 40,000 feet
  • Crew: 4
  • Engine: 2x Pratt & Whitney J-52-P-408 Turbojet Engines
